High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly

Changsha Tianwei Engineering Machinery Manufacturing Co., Ltd.
Contact Now

High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly

  • 1
  • 2

Brand Name : T-WORKS

Model Number : ZYC80

Certification : CE,GOST

Place of Origin : CHINA

MOQ : 1 Unit

Price : Negotiable

Payment Terms : L/C, T/T, D/A, Western Union

Delivery Time : 30-45 days after deposit received

Packaging Details : nude package for main body, plastic package for key parts

Supply Ability : 15 units per month

Product Name : Hydraulic Static Pile Driver

Piling Speed(m/min) : 4.5

Lifting Weight(t) : 5

Lifting Pile Length(m) : 8

Total Weight(t) : 80

Rated Piling Pressure(KN) : 800

Efficiency : 98%

Piling Stroke(m) : 1.6

Contact Now

High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly

1. Description:

ZYC series hydraulic static pile driver is a new environmentally friendly pile foundation construction equipment with a number of national patents. It has the features of no pollution, no noise, no vibration, and fast pile driving, high quality pile. It is represent the future development tendency of pilling machinery.

High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly

2. Applications:

  • Clay, soft soil, sand layer, etc.
  • Noise regulated urban area.
  • Vibration regulated areas where traditional methods may threaten the stability of existing structures.

3, Specifications:

Parameter/Model ZYC80
Rate piling pressure(KN) 800
Piling speed(m/min) Fast 4.5
Low 2.2
Piling stroke(m) 1.6
Pace(m) Longitudinal 1.5
Horizontal 0.4
Angle range(°) 15
Rise stroke(m) 1.25
Square pile(mm) Max 300
Circle pile(mm) Max 300
Side piling space(mm) 300
Corner piling space(mm) 500
Lifting weight(t) 5
Pile hanging length(m) 8
Power(KW) Piling 18..5
Lifting 11
Main dimension(m) Work length 5.4
Work width 3.9
Transportation height 2.0
Total weight(t) 80




4, Feature Advantage:
This mini pile driver can drive the precast concrete pile from 150mm to 300mm for square pile, 200mm to 300mm for round pile. It also can push the tube, triangle pile, H-pile, etc by changing its jaws inside of the clamping box.
The working size can be 6.5meters X 3.8meter, with attachable side piling machenism which is a special design for narrow project or inside of the workshop. Also nice for private house pile foundation.

High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly

1). Civilized construction; Clean; No noise; No vibrations; No construction wastes.
2). Reliable Construction Quality; Piling process is similar to static load testing, where pile bearing force can be displayed. 100% pile success rate is guaranteed.
3). Fast piling and High efficiency; One Hydraulic Static Pile Driver (shortened as HSPD )can drive piles in total of 600~800m per 8 hours, much faster than other modes. Especially suitable for large-scale or time-constraint projects.
4). Walking and steering freely. Easy to align piles.
5). Compact conformation. Easy to disassemble & assemble.

High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - FriendlyHigh Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly

High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly

High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly

5. After sale service and quality gurantee

1) To train operating,maintenance and construction people for our customers.

2) Always be ready to answer technical questions concerned from our customers.

3) Be responsible for the quality of our products and provide technical service of installing,making ajustment,testing and maintenance on the site in time.

4) To dispatch technicans to the worksite at short notice to solve problems or fix breakdowns.

5) Keep a record of our customers and be informed of the working performance of our products,feedback and suggestions of our customers so as to make a good cooperation with customers.
6) We guarantee to keep our Main Machine in good repair for 1 year after sale and 6 months for accessories. In the guarantee time, any quality problem caused by manufacturing after confirmation of us shall be repaired for free; Exceed the guarantee time, we can also supply repair services to our products charged for repair cost only.

High Speed Small Piling Machine ZYC80 With No Noise For Concrete Pile Foundation Eco - Friendly
